| ODORs and VOCs exhaust（Without Fan) | ||||||||
| Model | Power | Pressuer(Pa) | Air volume(m³/h) | Noise | Overall Size(mm) | flange size(mm) | Technology | TVOC,Benzene, Formaldehyde purified % |
| [dB(A)] | ||||||||
| LAD/KJD-DX2500 | 220V/50Hz | 400 | 2500 | 56 | 480*644*760 | 648*602 | 1.Pre filter 2.Photocatalyst 3.Actived Carbon filter 4.HEPA 5.UV lamp 6.High energy- Ionizer Above parts could be optional according to customer demand | 90% |
| LAD/KJD-DX3000 | 380V/50Hz | 400 | 3000 | 61 | 480*644*760 | 648*602 | ||
| LAD/KJD-DX4000 | 380V/50Hz | 400 | 4000 | 65 | 480*644*760 | 648*602 | ||
| LAD/KJD-DX5000 | 380V/50Hz | 400 | 5000 | 67 | 580*791*760 | 749*648 | ||
| LAD/KJD-DX6000 | 380V/50Hz | 400 | 6000 | 68 | 580*791*760 | 749*648 | ||
| LAD/KJD-DX9000 | 380V/50Hz | 550 | 9000 | 69 | 580*791*760 | 749*648 | ||
| LAD/KJD-DX12000 | 380V/50Hz | 590 | 12000 | 71 | 580*791*760 | 749*648 | ||
